Kyoritsu 3121B 2.5kV Insulation Tester
Kyoritsu 3121B 2.5kV Insulation Tester
SKU:KYR3121B
Regular price
$1,990.00 Ex GST
Regular price
$0.00 Ex GST
Sale price
$1,990.00 Ex GST
Unit price
/
per
Couldn't load pickup availability

Overview
A dual scale 2.5kV insulation tester from the world-class manufacturer, Kyoritsu. This tester automatically switches between low and high scales, with colour-coded LEDs to indicate the active scale. It features a newly designed alligator clip and comes with a durable hard case. Meets the IEC 61010-1 CAT IV 300V safety standard.
Applications
- Suitable for insulation testing up to 2.5kV
Tests
- Insulation resistance (2.5kV)
Features and Specifications
Insulation Measurements
- Measuring Range: 2GΩ/100GΩ
- Automatic Range: Autoranging
- First Effective Measuring Range: 0.1~50GΩ
- Accuracy: ±5% of reading
- Other Ranges Accuracy: ±10% of reading or 0.5% of scale length
General
- Withstand Voltage: 7058V AC for 1 minute
- Power Source: DC 12V (LR14/R14 × 8)
- Dimensions: 177(L) × 226(W) × 100(D) mm; Hard Case Dimensions: 300(L) × 315(W) × 125(D) mm
- Weight: Approximately 1.6 kg
Included Accessories
- 7165A Line Probe
- 7264 Earth Cord
- 7265 Guard Cord
- 8019 Hook Type Prod
- 9182 Hard Carrying Case
- LR14 Alkaline Batteries (Size C) × 8
- Instruction Manual
Standard Warranty
1 year
