Metrel Alpha MI 3340 Godex Print Pack

The Metrel Alpha EE MI 3340 Godex Print Pack brings appliance testing, data management and durable label printing together in one professional system. It pairs the powerful Alpha EE MI 3340 tester with a Godex RT200 thermal transfer printer, featuring Li-ion battery operation and a 2D QR code scanner. The Alpha EE’s touchscreen makes data entry straightforward, with predictive text removing the need for a separate tablet. Record appliance details in a simple format or capture more information across multiple fields.

The familiar Metrel interface makes it easy to build flexible site structures and assets. You can create structures on-the-go, prepare them in advance with ES Manager on a Windows PC, or use the optional MESM Android app. You can also upload previous test data and results to recall previous item and test details during testing. For retesting, scan the QR code to quickly retrieve the appliance’s recorded information. When each tested is completed, print tags wirelessly to the Godex printer via Bluetooth. The included rechargeable Li-ion battery includes a charge indicator for easy monitoring and straightforward charging.

ES Manager Pro is included, giving you complete control over test sequences. Pre-programmed tests to AS3760 are included or configure electrical tests and non-electrical inspections, with support for a range of steps, including prompts with text or images.

Testing appliances and leads in accordance with AS/NZS 3760:2022 with optional EVSE and 3-phase  testing

• • Earth Continuity – Yes (200mA)
  • Insulation Resistance – Yes (250V/500V)
  • Current Leakage – Yes
  • Max Current Leakage – 16A
  • Outlet Socket – 15A
  • Polarity – Yes
  • Portable RCD – Yes
  • Fixed RCD (CATII*) – Yes
  • Values Display – Yes
  • Battery Type – Li-Ion
  • Rechargeable – Yes
  • Programmable Sequences – Yes
  • Recording – Yes
  • Records Descriptions – Yes
  • Data Entry - Touch Screeen
  • Recall by ID# - Yes
  • Printer Option – Battery
  • Communications – USB/BT
  • 3 Phase Leakage Option** – Yes
  • Weight – 1.7 kg

*CATII - RCD testing from outlet sockets only
**Accessories purchased separately

• Includes printer – Yes
• Printer Power – Mains/Battery
• Records descriptions - Yes
• Non-electrical Test Recording – Yes
• Barcode scanning – QR/2D
• Recalls by ID#/Scan - Yes
• Custom logo – Yes
• Printer – Thermal transfer
• Printer Comms – BT
• Case – Hard
• Subscription for tester use – No
• Subscription required for reporting – No (Optional advanced subscription for ES Manager)
• System weight – 8kg

Godex RT200 Tag Printer, Li-Ion battery pack, 2D barcode scanner, Earth Test Lead, Military Case, Custom Foam, Probe, Crocodile Clip, Li-Ion Battery, 2 x IEC lead, Charger, Manual, USB cable, Certificate of Calibration, USB Cable, ES Manager Pro PC software, 250 White Test Tags.

Standard Warranty: 1 Year
